High erbium-doped ASE source using optical circulator and fiber loop mirror based on the double-pass double-stage configuration
Citation
Xiang-tao Lee, Sheng-peng Wan, and Hong-rong Shen, "High erbium-doped ASE source using optical circulator and fiber loop mirror based on the double pass double stage configuration," Proc. of SPIE Vol. 6781, Passive Components and Fiber-based Devices IV, 67812X (2007), doi: 10.1117/12.746804.
Keywords
- High erbium-doped
- Amplified Spontaneous Emission (ASE)
- ASE source
- Optical circulator
- Fiber loop mirror (FLM)
- Double-pass double-stage configuration
- Erbium-doped fiber (EDF)
- C-band
- L-band
- 980nm pumping
- 3dB line width
- Output power
- Spectral power
- Spectral plainness
- FBG sensors
- Fiber optical gyroscope
- DWDM system
- Optisystem 3.0
- Optical Spectrum Analyzer (OSA)
Brief
The article experimentally presents a high erbium-doped amplified spontaneous emission (ASE) source utilizing a double-pass double-stage configuration with an optical circulator and two fiber loop mirrors to achieve a broad bandwidth and improved output power.
Summary
This paper experimentally demonstrates a high-power and broad-bandwidth Amplified Spontaneous Emission (ASE) source using a double-pass double-stage configuration that combines an optical circulator with two fiber loop mirrors (FLMs). The design utilizes highly erbium-doped fiber (4000ppm) to achieve an output power of over 0.79 dBm with a 3dB bandwidth of 85.3 nm spanning the C and L bands (1526-1611.3 nm). This compact ASE source is suitable for applications in fiber Bragg grating (FBG) sensors, fiber optical gyroscopes, and DWDM systems. Simulations suggest the potential for even wider bandwidth and higher output power.
