Multivariable Analysis of Nonlinear Optical Loop Mirror Operating Parameters Using Jones Matrices and Three-Dimensional Renderings

Citation

Filoteo-Razo, J.D.; Hernandez-Garcia, J.C.; Estudillo-Ayala, J.M.; Pottiez, O.; Martinez-Angulo, J.R.; Barron-Zambrano, J.H.; Elizondo-Leal, J.C.; Saldivar-Alonso, V.P.; Lauterio-Cruz, J.P.; Rojas-Laguna, R. (2023). Multivariable Analysis of Nonlinear Optical Loop Mirror Operating Parameters Using Jones Matrices and Three-Dimensional Renderings. Photonics, 10(10), 1071. https://doi.org/10.3390/photonics10101071.

Keywords

• NOLM (abbreviation for nonlinear optical loop mirror)
• Jones matrix formalism
• Multivariable analysis
• Operating parameters (of NOLM)
• Low-power transmission
• High-power transmission
• Dynamic range (DR)
• Fiber loop length (L)
• Input power (Pin)
• Angle of retarder plate (α) (specifically quarter-wave retarder (QWR))
• Input polarization (linear and circular)
• Switching power (Pπ)
• Critical power
• Ultrafast pulse generation
• Optical signal processing
• Optical communication systems
• Photonic integrated circuits
• Nonlinear polarization rotation (NPR)

Brief

This article presents a numerical analysis of a nonlinear optical loop mirror (NOLM) using the Jones matrix formalism and 3D plots to investigate the impact of various parameters like fiber loop length, input power, and polarization on its performance for applications in fiber optic devices and optical communications.

Summary

This article presents a numerical study of a nonlinear optical loop mirror (NOLM) using Jones matrices and 3D plots to analyze how parameters like fiber loop length, input power, QWR angle, and input polarization affect its performance. The research investigates both linear and circular input polarizations and their influence on switching power and dynamic range. The findings demonstrate that adjusting the QWR for circular polarization and the HWR for linear polarization allows for greater control over NOLM operating conditions, which is crucial for applications such as ultrafast pulse generation in figure-eight lasers (F8Ls) where the NOLM can function as a saturable absorber (SA). The 3D visualizations provide a detailed understanding of the NOLM's transmission characteristics to determine optimal high- and low-power operation.
